Characteristic and Relative Expression Pattern Analysis of FWL/PLAC8 Family in Blueberry

doi:10.16420/j.issn.0513-353x.2020-0151

Acta Horticulturae Sinica ›› 2021, Vol. 48 ›› Issue (2): 336-346.doi: 10.16420/j.issn.0513-353x.2020-0151

• Research Notes • Previous Articles Next Articles

Characteristic and Relative Expression Pattern Analysis of FWL/PLAC8 Family in Blueberry

YU Lei¹, ZHOU Ya¹, ZONG Yu¹^,², ZHANG Ying¹, QIU Jiaqi¹, LI Yongqiang¹^,², YANG Li¹^,²^,^*(), GUO Weidong¹^,²^,^*()

¹College of Chemistry and Life Sciences,Zhejiang Normal University,Jinhua,Zhejiang 321004,China
²Zhejiang Provincial Key Laboratory of Biotechnology on Specialty Economic Plants,Zhejiang Normal University,Jinhua,Zhejiang 321004,China

Received:2020-05-08 Revised:2020-08-25 Online:2021-02-25 Published:2021-03-09
Contact: YANG Li,GUO Weidong E-mail:yangli@zjnu.edu.cn;gwd@zjnu.cn

Abstract

Abstract:

Fruit size and weight are the most vital agronomic characters for consumers,breeders and researchers,and fruit weight（FW）was reported as an important quantitative trait locus affecting tomato and other fruit weight and size remarkably. In this study,the growth curves during Vaccinium corymbosum ‘O’Neal’（large-size fruit）and‘Bluerain’（small-size fruit）flower bud enlargement and fruit development,and conventionally physical indexes of mature fruits were measured and analyzed. The FWL family with conserved domain PLAC8 in the blueberry genome was identified,and the gene structure, chromosome location,conserved motifs of VcFWL/PLAC8 were analyzed. The relative expression level of VcFWL/PLAC8 genes during‘O’Neal’and‘Bluerain’flower bud enlargement and fruit development was detected by real-time fluorescence quantitative PCR. The results showed that the fruit weight of‘O’Neal’was dramatically higher than that of‘Bluerain’from stage S2,and the locule number,seed number and weight per fruit of‘O’Neal’mature fruits were also notably higher than those of‘Bluerain’. The VcFWL/PLAC8 family contained 11 members with highly conserved motifs in the‘Draper’genome,which can be divided into three clusters. qRT-PCR analysis showed that the expression patterns of A and C subfamilies were consistant with opposite to the cell proliferation trend,while the expression level of B subfamily was relatively low. These results suggested that VcFWL/PLAC8 genes might be involved in fruit growth and development through different regulatory mechanisms and pathways.

Key words: blueberry, FWL/PLAC8, Vaccinium corymbosum, fruit size, fruit development

CLC Number:

S663.9

YU Lei, ZHOU Ya, ZONG Yu, ZHANG Ying, QIU Jiaqi, LI Yongqiang, YANG Li, GUO Weidong. Characteristic and Relative Expression Pattern Analysis of FWL/PLAC8 Family in Blueberry[J]. Acta Horticulturae Sinica, 2021, 48(2): 336-346.

Figures/Tables 8

References 41

[1]	Alpert K B, Tanksley S D. 1996. High-resolution mapping and isolation of a yeast artificial chromosome contig containing fw2.2:a major fruit weight quantitative trait locus in tomato. Proceedings of the National Academy of Sciences of the United States of America, 93:5503-15507.
[2]	Bailey T L, Boden M, Buske F A, Frith M, Grant C E, Clementi L, Ren J Y, Li W W, Noble W S. 2009. MEME SUITE:tools for motif discovery and searching. Nucleic Acids Research, 37(Supplement 2):W202-W208. doi: 10.1093/nar/gkp335 URL
[3]	Bertin N. 2005. Analysis of the tomato fruit growth response to temperature and plant fruit load in relation to cell division,cell expansion and DNA endoreduplication. Annals of Botany, 95:439-447. doi: 10.1093/aob/mci042 URL
[4]	Busov V B, Brunner A M, Strauss S H. 2008. Genes for control of plant stature and form. New Phytologist, 177:589-607. doi: 10.1111/nph.2008.177.issue-3 URL
[5]	Cabreira-Cagliari C, Dias N D, Bohn B, Fagundes D G D, Margis-Pinheiro M, Bodanese-Zanettini M H, Cagliari A. 2018. Revising the PLAC8 gene family:from a central role in differentiation,proliferation,and apoptosis in mammals to a multifunctional role in plants. Genome, 61:857-865. doi: 10.1139/gen-2018-0035 pmid: 30427722
[6]	Chen Man-man. 2019. Comparative analysis of anatomy and cell-cy.le related genes of southern highbush Vaccinium corymbosum[M. D. Dissertation]. Jinhua:Zhejiang Normal University. (in Chinese)
	陈曼曼. 2019. 南高丛蓝莓果实发育细胞学规律及相关基因的分离与表达分析[硕士论文]. 金华:浙江师范大学.
[7]	Dernisky A K, Evans R C, Liburd O E, Mackenzie K. 2005. Characterization of early floral damage by cranberry tipworm(Dasineura oxycoccana Johnson)as a precursor to reduced fruit set in rabbiteye blueberry(Vaccinium ashei Reade). International Journal of Pest Management, 51:143-148. doi: 10.1080/09670870500130980 URL
[8]	Die J V, Rowland L J. 2013. Advent of genomics in blueberry. Molecular Breeding, 32:493-504. doi: 10.1007/s11032-013-9893-1 URL
[9]	Doebley J F, Gaut B S, Smith B D. 2006. The molecular genetics of crop domestication. Cell, 127:1309-1321. pmid: 17190597
[10]	Frary A, Nesbitt T C, Grandillo S, van der Knaap E, Cong B, Liu J, Meller J, Elber R, Alpert K B, Tanksley S D. 2000. fw2.2:a quantitative trait locus key to the evolution of tomato fruit size. Science, 289:85-88. doi: 10.1126/science.289.5476.85 URL
[11]	Gonzalez N, Beemster G T, Inze D. 2009. David and Goliath: what can the tiny weed Arabidopsis teach us to improve biomass production in crops? Current Opinion in Plant Biology, 12:157-164. doi: 10.1016/j.pbi.2008.11.003 URL
[12]	Gonzalez N, De Bodt S, Sulpice R, Jikumaru Y, Chae E, Dhondt S, van Daele T, De Milde L, Weigel D, Kamiya Y, Stitt M, Beemster G T S, Inze D. 2010. Increased leaf size:different means to an end. Plant Physiology, 153 : 1261-1279. doi: 10.1104/pp.110.156018 URL
[13]	Grandillo S, Ku H M, Tanksley S D. 1999. Identifying the loci responsible for natural variation in fruit size and shape in tomato. Theoretical and Applied Genetics, 99:978-987. doi: 10.1007/s001220051405 URL
[14]	Guo M, Rupe M A, Dieter J A, Zou J, Spielbauer D, Duncan K E, Howard R J, Hou Z, Simmons C R. 2010. Cell Number Regulator1 affects plant and organ size in maize:implications for crop yield enhancement and heterosis. The Plant Cell, 22:1057-1073. doi: 10.1105/tpc.109.073676 URL
[15]	Guo M, Simmons C R. 2011. Cell number counts-The fw2.2 and CNR genes and implications for controlling plant fruit and organ size. Plant Science, 181:1-7. doi: 10.1016/j.plantsci.2011.03.010 URL
[16]	He Chao-ying, Wang Li, Yan Li-xin, Li Qiao-ru, Yong Bin, Zhu Wei-wei. 2019. Evolutionary developmental mechanisms underlying the origin and diversification of the fruits. Scientia Sinica(Vitae), 49(4):301-319. (in Chinese)
	贺超英, 王丽, 严立新, 李巧茹, 雍斌, 朱韦韦. 2019. 果实起源与多样化的进化发育机制. 中国科学:生命科学, 49(4):301-319.
[17]	Hussain Q, Shi J Q, Scheben A, Zhan J P, Wang X F, Liu G H, Yan G J, King G J, Edwards D, Wang H Z. 2020. Genetic and signaling pathways of dry fruit size: targets for genome editing based crop improvement. Plant Biotechnology Journal, 18(5) : 1124-1140. doi: 10.1111/pbi.13318 pmid: 31850661
[18]	Janssen B J, Thodey K, Schaffer R J, Alba R, Balakrishnan L, Bishop R, Bowen J H, Crowhurst R N, Gleave A P, Ledger S, McArtney S, Pichler F B. 2008. Global gene expression analysis of apple fruit development from the floral bud to ripe fruit. BMC Plant Biology, 8:16. doi: 10.1186/1471-2229-8-16 pmid: 18279528
[19]	Letunic L, Bork P. 2019. Interactive tree of life(iTOL)v4:recent updates and new developments. Nucleic Acids Research, 47(1):256-259.
[20]	Li X B, Jin L, Pan X H, Yang L, Guo W D. 2019. Proteins expression and metabolite profile insight into phenolic biosynthesis during highbush blueberry fruit maturation. Food Chemistry, 290:216-228. doi: 10.1016/j.foodchem.2019.03.115 URL
[21]	Li Ya-dong, Pei Jia-bo, Sun Hai-yue. 2018. Status and prospect of global blueberry industry. Journal of Jilin Agricultural University, 40(4):421-432. (in Chinese)
	李亚东, 裴嘉博, 孙海悦. 2018. 全球蓝莓产业发展现状及展望. 吉林农业大学学报, 40(4):421-432.
[22]	Libault M, Stacey G. 2010. Evolution of FW2.2-like (FWL) and PLAC8 genes in eukaryotes. Plant Signaling & Behavior, 5(10):1226-1228.
[23]	Libault M, Zhang X C, Govindarajulu M, Qiu J, Ong Y T, Brechenmacher L, Berg R H, Hurley-Sommer A, Taylor C G, Stacey G. 2010. A member of the highly conserved FWL(tomato FW2.2-like)gene family is essential for soybean nodule organogenesis. The Plant Journal, 62:852-864. doi: 10.1111/j.1365-313X.2010.04201.x pmid: 20230508
[24]	Lin Y, Wang Y H, Li B, Tan H, Li D N, Li L, Liu X, Han J C, Meng X J. 2018. Comparative transcriptome analysis of genes involved in anthocyanin synthesis in blueberry. Plant Physiology and Biochemistry, 127:561-572. doi: 10.1016/j.plaphy.2018.04.034 URL
[25]	Livak K J, Schmittgen T D. 2001. Analysis of relative gene expression data using real-time quantitative PCR and the 2^-ΔΔCT method. Methods, 25(4):402-408. pmid: 11846609
[26]	Monforte A J, Diaz A I, Caño-Delgado A, van der Knaap E. 2014. The genetic basis of fruit morphology in horticultural crops:lessons from tomato and melon. Journal of Experimental Botany, 65(16):4625-4637. doi: 10.1093/jxb/eru017 pmid: 24520021
[27]	Pan Y, Wang Y, McGregor C, Liu S, Luan F, Gao M, Weng Y. 2020. Genetic architecture of fruit size and shape variation in cucurbits: a comparative perspective. Theoretical and Applied Genetics, 133(1):1-21. doi: 10.1007/s00122-019-03481-3 URL
[28]	Renaudin J P, Deluche C, Cheniclet C, Chevalier C, Frangne N. 2017. Cell layer-specific patterns of cell division and cell expansion during fruit set and fruit growth in tomato pericarp. Journal of Experimental Botany, 68:1613-1623. doi: 10.1093/jxb/erx058 URL
[29]	Rowland L J, Alkharouf N, Darwish O, Ogden E L, Polashock J J, Bassil N V, Main D. 2012. Generation and analysis of blueberry transcriptome sequences from leaves,developing fruit,and flower buds from cold acclimation through deacclimation. BMC Plant Biology, 12:46. doi: 10.1186/1471-2229-12-46 pmid: 22471859
[30]	Song W Y, Martinoia E, Lee J, Kim D, Kim D Y, Vogt E, Shim D, Choi K S, Hwang I, Lee Y. 2004. A novel family of cys-rich membrane proteins mediates cadmium resistance in Arabidopsis. Plant Physiology, 135(2):1027-1039. doi: 10.1104/pp.103.037739 URL
[31]	Su W B, ZhuY M, Zhang L, Yang X H, Gao Y S, Lin S Q. 2017. The cellular physiology of loquat(Eriobotrya japonica Lindl.)fruit with a focus on how cell division and cell expansion processes contribute to pome morphogenesis. Scientia Horticulturae, 224:142-149. doi: 10.1016/j.scienta.2017.06.012 URL
[32]	Tamura K, Peterson D, Peterson N, Stecher G, Nei M, Kumar S. 2011. MEGA5:molecular evolutionary genetics analysis using maximum likelihood,evolutionary distance,and maximum parsimony methods. Molecular Biology and Evolution, 28(10):2731-2739. doi: 10.1093/molbev/msr121 URL
[33]	Tanksley S D. 2004. The genetic,developmental,and molecular bases of fruit size and shape variation in tomato. The Plant Cell, 16:S181-S189. doi: 10.1105/tpc.018119 URL
[34]	Wang Yan. 2015. The roles of kinesins in exponential cell production and enlargement during early fruit development[Ph. D. Dissertation]. Beijing:Chinese Academy of Agricultural Science. (in Chinese)
	王燕. 2015. 黄瓜动蛋白参与果实发育早期细胞分裂和细胞膨大过程的研究[博士论文]. 北京:中国农业科学院.
[35]	Xu J, Xiong W, Cao B, Yan T, Luo T, Fan T, Luo M. 2013a. Molecular characterization and functional analysis of“fruit-weight2.2-like”gene family in rice. Planta, 238:643-655. doi: 10.1007/s00425-013-1916-y URL
[36]	Xu Jing, Pan Yu-peng, Cheng Zhi-hui. 2020. Mechanism analysis of fruit size regulating genes CsSUN and CsLNG1 in cucumber. Acta Horticulturae Sinica, 47(1):53-62. (in Chinese)
	徐婧, 潘玉朋, 程智慧. 2020. 黄瓜CsSUN和CsLNG1调控果实大小的机理分析. 园艺学报, 47(1):53-62.
[37]	Xu T F, Xiang J, Li F J, Li T M, Yu Y H, Wang Y J, Xu Y. 2013b. Screening proteins interacting with VpPR10.1 of Chinese wild grapevine using the yeast two-hybrid system. Acta Physiologiae Plantarum, 35:2355-2364. doi: 10.1007/s11738-013-1269-y URL
[38]	Yang L, Cai K L, Huang H Y, Zhang Y H, Zong Y, Wang S, Shi J L, Li X P, Liao F L, Lu M, Guo W D. 2019. Comparative analysis of anatomy,gene expression of Vaccinium corymbosum cyclins and cyclin dependent kinases during the flower bud and fruit ontogeny. Scientia Horticulturae, 251:252-259. doi: 10.1016/j.scienta.2019.03.028
[39]	Yang L, Chen M M, Cai K L, Zhang L J, Zhu Y F, Ye Q, Lu M, Liao F L, Chen W R, Guo W D. 2018. VcFAS,VcSUN and VcOVATE orchestrated the fruit morphogenesis in southern highbush blueberry during the pre-anthesis and fruit development. Scientia Horticulturae, 240:109-115. doi: 10.1016/j.scienta.2018.05.023 URL
[40]	Yu Ke-da, Ye Mei-juan, Chen Wen-rong, Zhu Kai-li, Zhang Chang-jing, Guo Wei-dong. 2016. Methods for RNA isolation from blueberry tissues. Journal of Zhejiang Normal University(Natural Sciences), 39(1):66-70. (in Chinese)
	余柯达, 叶美娟, 陈文荣, 朱凯丽, 张常晶, 郭卫东. 2016. 蓝莓组织RNA提取方法的研究. 浙江师范大学学报(自然科学版), 39(1):66-70.
[41]	Zifkin M, Jin A, Ozga J A, Zaharia L I, Schernthaner J P, Gesell A, Abrams S R, Kennedy J A, Constabel C P. 2012. Gene expression and metabolite profiling of developing highbush blueberry fruit indicates transcriptional regulation of flavonoid metabolism and activation of abscisic acid metabolism. Plant Physiology, 158:200-224. doi: 10.1104/pp.111.180950 URL

引物名称 Primer name	上游引物（5′-3′） Forward primer	下游引物（5′-3′） Reverse primer	扩增长度/bp Predicted length
A subfamily	TCAGACATCCTTCCCACTAACC	CCGTCGCAGGAGACGTAG	138
B subfamily	CCAGGGTTTCGCTCTCCTTCC	AGCTCCCTTGGCCTGCGG	186
C subfamily	TCTGCGAAAGGTCTGGAGAT	CATGGCAACCAACATTTCAG	285
VcGAPDH	CGGCTACTTACGAGCAAATCAA	TTCAGTGTAGCCCAAAATTCCTTT	80

引物名称 Primer name	上游引物（5′-3′） Forward primer	下游引物（5′-3′） Reverse primer	扩增长度/bp Predicted length
A subfamily	TCAGACATCCTTCCCACTAACC	CCGTCGCAGGAGACGTAG	138
B subfamily	CCAGGGTTTCGCTCTCCTTCC	AGCTCCCTTGGCCTGCGG	186
C subfamily	TCTGCGAAAGGTCTGGAGAT	CATGGCAACCAACATTTCAG	285
VcGAPDH	CGGCTACTTACGAGCAAATCAA	TTCAGTGTAGCCCAAAATTCCTTT	80

品种 Cultivar	百粒种子质量/g Weight / 100 seeds	单果种子数 Seed number	单果种子质量/g Seed weight pre fruit	心室数比例/% Locule number
品种 Cultivar	百粒种子质量/g Weight / 100 seeds	单果种子数 Seed number	单果种子质量/g Seed weight pre fruit	4	5	6	7
奥尼尔O’Neal	0.04 ± 0.00	83.00 ± 4.06^**	0.036 ± 0.007^**		57.39	21.09	16.52
蓝雨Bluerain	0.04 ± 0.00	30.42 ± 8.31	0.012 ± 0.004	1.64	98.36

品种 Cultivar	百粒种子质量/g Weight / 100 seeds	单果种子数 Seed number	单果种子质量/g Seed weight pre fruit	心室数比例/% Locule number
品种 Cultivar	百粒种子质量/g Weight / 100 seeds	单果种子数 Seed number	单果种子质量/g Seed weight pre fruit	4	5	6	7
奥尼尔O’Neal	0.04 ± 0.00	83.00 ± 4.06^**	0.036 ± 0.007^**		57.39	21.09	16.52
蓝雨Bluerain	0.04 ± 0.00	30.42 ± 8.31	0.012 ± 0.004	1.64	98.36

基因名称 Gene name	染色体位置 Chromosome location	CDS/bp	外显子数 Exon number	大小/aa Size	分子量/kD Molecular weight	等电点 pI
gene-169.8	VaccDscaff5：16978476..16983996-	561	3	186	20.39	5.60
gene-244.19	VaccDscaff8：24434249..24439769+	693	2	230	25.72	4.92
gene-228.26	VaccDscaff10：22828768..22834442+	672	4	223	24.22	5.35
gene-180.23	VaccDscaff1：18011712..18017230-	777	3	258	27.84	8.12
gene-48.40	VaccDscaff27：4876429..4880014+	741	3	246	26.38	5.40
gene-85.17	VaccDscaff17：8569670..8572170+	657	2	218	23.42	8.54
gene-85.18	VaccDscaff17：8572400..8573369+	396	2	131	14.60	6.27
gene-305.30	VaccDscaff34：30578948..30582561-	738	3	246	26.40	5.37
gene-296.30	VaccDscaff29：29591240..29601268-	603	3	200	21.34	4.76
gene-308.41	VaccDscaff26：30828379..30838346-	603	3	200	21.34	4.76
gene-316.28	VaccDscaff21：31596223..31606319-	603	3	200	21.30	4.76
VcFW2.2	v.corymbosum_GDV_reftransV1_0004680	732	/	243	26.32	5.97
