基于重测序的‘金兰柚’基因组InDel标记的开发及应用

doi:10.16420/j.issn.0513-353x.2021-0935

摘要/Abstract

摘要：

基于重测序进行金兰柚全基因组InDel标记开发。利用二代测序技术对‘金兰柚’进行全基因组重测序，运用BWA软件将测序得到的片段与参考基因组序列进行比对，利用严格的参数筛选杂合InDel，结合Primer 3.0设计扩增引物，进行PCR扩增并利用琼脂糖凝胶电泳验证，以重测序材料‘金兰柚’和47份柚品种检测其有效性。在全基因组范围内共筛选出81对扩增条带清晰的引物。筛选出的多态性标记涵盖了整个‘金兰柚’基因组，平均每条染色体上9个。选取的24对 InDel 标记可以将48份柚品种有效区分，最少使用2对引物就可将‘金兰柚’与其他47份柚品种完全区分。利用UPGMA构建48份柚品种的聚类树状图，在遗传相似系数为0.611的阈值处可将48个柚品种分为3大类群。本研究中的InDel标记带型简单易读，适宜柚DNA指纹图谱构建和品种鉴定，可为柚名优品种保护、原产地溯源管理等提供科学依据。

关键词: 柚, 重测序, InDel标记

Abstract:

This study developed a genome-wide InDel marker map of Jinlan pummelo（Citrus maxima）genome. The next generation sequencing（NGS）technology was applied to produce the deep resequencing data of the individual，and was mapped to the reference genome using BWA-MEM. The pipeline with strict parameters improved accuracy and effectiveness of heterozygous InDel markers. The primers designment was performed by using Primer 3.0. The agarose gel electrophoresis of polymerase chain reaction（PCR）product was used to validate the effectiveness of primers. A total of 81 effective paired primers were identified. The corresponding markers covered nearly the whole genome of Jinlan pummelo，with an average number of nine InDel markers per chromosome. Of these markers，24 markerswere succussed in distinguishing the 48 pummelo individuals，which showed that two paired markers could distinguish Jinlan pummelo and other 47 pummelo individuals. Finally，UPGMA was used to construct the phylogeny of 48 pummelo，which was divided into three groups at threshold 0.611 of genetic similarity coefficient. This study suggested that the genome-wide InDel markers developed using deep resequencing was suitable for the identification of the different germplasms of pummelo，and provides a basis in variety protection and origin traceability management.

Key words: pummelo, re-sequencing, InDel marker

中图分类号:

S666.3

汤雨晴, 杨惠栋, 闫承璞, 王斯妤, 王雨亭, 胡钟东, 朱方红. 基于重测序的‘金兰柚’基因组InDel标记的开发及应用[J]. 园艺学报, 2023, 50(1): 15-26.

TANG Yuqing, YANG Huidong, YAN Chengpu, WANG Siyu, WANG Yuting, HU Zhongdong, ZHU Fanghong. Development and Application of Jinlan Pummelo（Citrus maxima）InDel Markers Based on Genome Re-sequencing[J]. Acta Horticulturae Sinica, 2023, 50(1): 15-26.

图/表 7

参考文献 43

[1]	Adedze Y M N, Lu X, Xia Y C, Sun Q Y, Nchongboh C G, Alam M A, Liu M H, Yang X, Zhang W T, Deng Z J, Li W H, Si L T. 2021. Agarose-resolvable InDel markers based on whole genome re-sequencing in cucumber. Scientific Reports, 11 (1):3872-3883. doi: 10.1038/s41598-021-83313-x pmid: 33594240
[2]	Andres G L, Franck C, Hager S T, Raphael M, Gema A, François L, Luis N, Patrick O. 2013. A nuclear phylogenetic analysis:SNPs,indels and SSRs deliver new insights into the relationships in the‘true citrus fruit trees’group(Citrinae,Rutaceae)and the origin of cultivated species. Annals of Botany, 111 (1):1-19. doi: 10.1093/aob/mcs227 URL
[3]	Bastos-Rodrigues L, Pimenta J R, Pena S D J. 2006. The genetic structure of human populations studied through short insertion-deletion polymorphisms. Annals of Human Genetics, 70 (5):658-665. doi: 10.1111/j.1469-1809.2006.00287.x pmid: 29488221
[4]	Chen R, Chang L C, Cai X, Wu J, Liang J L, Lin R M, Song Y, Wang X W. 2021. Development of InDel markers for Brassica rapa based on a High-resolution Melting Curve. Horticultural Plant Journal, 7 (1):31-37. doi: 10.1016/j.hpj.2020.05.003 URL
[5]	Fang Q Y, Wang L, Yu H W, Huang Y, Jiang X L, Deng X X, XU Q. 2018. Development of Species-Specific InDel markers in citrus. Plant Molecular Biology Reporter, 36 (4):653-662. doi: 10.1007/s11105-018-1111-1 URL
[6]	Feng Fang-jun, Luo Li-jun, Li Ying, Zhou Li-guo, Xu Xiao-yan, Wu Jin-hong, Chen Hong-wei, Chen Liang, Mei Han-wei. 2005. Comparative analysis of polymorphism of InDel and SSR markers in rice. Molecular Plant Breeding, 3 (5):725-730. (in Chinese)
	冯芳君, 罗利军, 李荧, 周立国, 徐小艳, 吴金红, 陈宏伟, 陈亮, 梅捍卫. 2005. 水稻InDel和SSR标记多态性的比较分析. 分子植物育种, 3 (5):725-730.
[7]	Gao Q, Yue G, Li W, Wang J, Xu J, Yin Y. 2012. Recent progress using high-throughput sequencing technologies in plant molecular breeding. Journal of Integrative Plant Biology, 54 (4):215-227. doi: 10.1111/j.1744-7909.2012.01115.x
[8]	Gu Qing-qing, Zeng Tao, Wei Qing-jiang, Zou Ju-hua, Chen Jin-yin. 2017. Study on genetic relationship of nanfeng citrus germplasm resources based on SSR marker technology. Journal of Fruit Science, 34 (6):653-659. (in Chinese)
	辜青青, 曾涛, 魏清江, 邹菊花, 陈金印. 2017. 基于SSR标记技术的南丰柑橘种质资源亲缘关系研究. 果树学报, 34 (6):653-659.
[9]	Guo Fei. 2015. Construction of genetic map of citrus and study on the regulation of carotenoid metabolism[Ph. D. Dissertation]. Wuhan: Huazhong Agricultural University. (in Chinese)
	郭飞. 2015. 柑橘遗传图谱构建及类胡萝卜素代谢调控研究[博士论文]. 武汉: 华中农业大学.
[10]	He Tainfu. 1999. Cultivation of pomelo in China. Beijing: China Agriculture Press. (in Chinese)
	何天富. 1999. 中国柚类栽培. 北京: 中国农业出版社.
[11]	Huang Yuan-ji, Qian Hao. 2003. Storable pomelo variety——Jinlan pomelo. Information on Citrus and Subtropical Fruit Trees, 19 (10):24-25. (in Chinese)
	黄渊基, 覃皓. 2003. 耐贮柚品种——金兰柚. 柑橘与亚热带果树信息, 19 (10):24-25.
[12]	Hyten D L, Cannon S B, Song Q, Weeks N, Fickus E W, Shoemaker R C, Specht J E, Farmer A D, May G D, Cregan P B. 2010. High-throughput SNP discovery through deep resequencing of a reduced representation library to anchor and orient scaffolds in the soybean whole genome sequence. BMC Genomics, 11 (1):1248-1251.
[13]	Jander G, Norris S R, Rounsley S D, Bush D F, Levin I M, Last R L. 2002. Arabidopsis map-based cloning in the post-genome era. Plant Physiology, 129 (2):440-450. doi: 10.1104/pp.003533 pmid: 12068090
[14]	Jin L, Zhao L P, Wang Y L, Zhou R, Song L X, Xu L P, Cui X, Li R, Yu W G, Zhao T M. 2019. Genetic diversity of 324 cultivated tomato germplasm resources using agronomic traits and InDel markers. Springer Netherlands,215 (4):69-84.
[15]	Li Hang, Yang Xiao-ming, Ding De-kuan, Wang Xiao-li, Xie Zong-zhou, Ye Jun-li, Peng Shu-ang, Deng Xiu-xin, Chai Li-jun. 2018. Parentage analysis of indigenous citrus species‘Zhi Que’based on nuclear and chloroplast SSR markers. Journal of Fruit Science, 35 (10):1161-1169. (in Chinese)
	李航, 杨晓明, 丁德宽, 王小丽, 谢宗周, 叶俊丽, 彭抒昂, 邓秀新, 柴利军. 2018. 基于cpSSR和nSSR标记的地方柑橘资源‘枳雀’亲本分析. 果树学报, 35 (10):1161-1169.
[16]	Li Xian-xin, Yang Ying-hua, Chen Jie-ping, Zou Xue-xiao, Deng Zi-niu. 2013. Genetic diversity and genetic relationship of pomelo germplasm resources in hunan. Journal of Hunan Agricultural University(Natural Science Edition), 39 (4):363-370. (in Chinese)
	李先信, 杨迎花, 陈婕平, 邹学校, 邓子牛. 2013. 湖南柚种质资源的遗传多样性和亲缘关系. 湖南农业大学学报(自然科学版), 39 (4):363-370.
[17]	Liang Wu-jun, Xie Kai-dong, Guo Da-yong, Xie Zong-zhou, Xu Qiang, Yi Hua-lin, Guo Wen-wu. 2014. Excavation and SSR identification of polyploids in the offspring of 10 citrus cultivars. Acta Horticulturae Sinica, 41 (3):409-416. (in Chinese)
	梁武军, 解凯东, 郭大勇, 谢宗周, 徐强, 伊华林, 郭文武. 2014. 柑橘10个品种实生后代多倍体的发掘及SSR鉴定. 园艺学报, 41 (3):409-416.
[18]	Liu B, Wang Y, Zhai W, Deng J, Wang H, Cui Y, Cheng F, Wang X W, Wu J. 2013. Development of InDel markers for Brassica rapa based on whole-genome re-sequencing. Theoretical and Applied Genetics, 126 (1):231-239. doi: 10.1007/s00122-012-1976-6 pmid: 22972202
[19]	Liu Bing-hao, Deng Chong-ling, Chen Chuan-wu, Deng Guang-zhou, Ding Ping, Niu Ying, Tang Yan, Fu Hui-min. 2015. ISSR analysis of citrus resources in Guangxi. Journal of Fruit Science, 32 (6):1001-1006. (in Chinese)
	刘冰浩, 邓崇岭, 陈传武, 邓光宙, 丁萍, 牛英, 唐艳, 付慧敏. 2015. 广西地方柑橘资源的ISSR分析. 果树学报, 32 (6):1001-1006.
[20]	Liu J, Qu J T, Yang C, Tang D G, Li J W, Lan H, Rong T Z. 2015. Development of genome-wide insertion and deletion markers for maize,based on next-generation sequencing data. BMC Genomics, 16 (1):601-609. doi: 10.1186/s12864-015-1797-5 URL
[21]	Liu Sheng-rui. 2016. Construction of high density genetic linkage map of citrus and QTL mapping of deciduous traits[Ph. D. Dissertation]. Wuhan: Huazhong Agricultural University. (in Chinese)
	刘升锐. 2016. 柑橘高密度遗传连锁图谱的构建及落叶性状的QTL定位[博士论文]. 武汉: 华中农业大学.
[22]	Liu Yong, Liu Dechun, Wu Bo, Sun Zhonghai. 2006. Genetic diversity of pomelo resources and related species in China using SSR markers. Journal of Agricultural Biotechnology, 14 (1):90-95. (in Chinese)
	刘勇, 刘德春, 吴波, 孙中海. 2006. 利用SSR标记对中国柚类资源及近缘种遗传多样性研究. 农业生物技术学报, 14 (1):90-95.
[23]	Liu Yong, Sun Zhong-hai, Liu De-chun, Wu Bo, Tao Jian-jun. 2005. Genetic diversity analysis of pomelo germplasm resources by AFLP and SSR markers. Scientia Agricultura Sinica, 38 (11):165-172. (in Chinese)
	刘勇, 孙中海, 刘德春, 吴波, 陶建军. 2005. 柚类种质资源AFLP与SSR遗传多样性分析. 中国农业科学, 38 (11):165-172.
[24]	Lv H H, Yang L M, Kang J G, Wang Q B, Wang X W, Fang Z Y, Liu Y M, Zhuang M, Zhang Y Y, Lin Y, Yang Y H, Xie B Y, Liu B, Liu J S. 2013. Development of InDel markers linked to Fusarium wilt resistance in cabbage. Molecular Breeding, 32 (4):961-967. doi: 10.1007/s11032-013-9925-x URL
[25]	Ma Li-li, Xie Kai-dong, Ye Jun-li, Guo Wen-wu. 2013. Phylogenetic relationship for early flowering lemon by SSR markers. Journal of Fruit Science, 30 (3):381-385. (in Chinese)
	马丽丽, 解凯东, 叶俊丽, 郭文武. 2013. 基于 SSR 标记的早花柠檬亲缘关系分析. 果树学报, 30 (3):381-385.
[26]	Pacurar D I, Pcurar M L, Street N, Bussell J D, Pop T I, Gutierrez L, Bellini C. 2012. A collection of INDEL markers for map-based cloning in seven Arabidopsis accessions. Journal of Experimental Botany, 63 (7):2491-2501. doi: 10.1093/jxb/err422 URL
[27]	Pan C H, Ai-Hong L I, Dai Z Y, Zhang H X, Liu G Q, Wang Z B, Yu-Yin M A, Yin Y J, Zhang Y F, Zuo S M. 2008. InDel and SNP markers and their applications in map-based cloning of rice genes. Rice Science, 15 (4):251-258. doi: 10.1016/S1672-6308(09)60001-9 URL
[28]	Pang Xiao-ming. 2002. Genetic diversity of Citrus and its related genera and Citrus trifoliate(Citrus)by molecular markers [Ph. D. Dissertation]. Wuhan: Huazhong Agricultural University. (in Chinese)
	庞晓明. 2002. 用分子标记研究柑橘属及其近缘属植物的亲缘关系和枳的遗传多样性[博士论文]. 武汉: 华中农业大学.
[29]	Pradosh M, Sankar K G. 2014. Utility of indels for species-level identification of a biologically complex plant group:a study with intergenic spacer in Citrus. Molecular Biology Reports, 41 (11):7217-7222. doi: 10.1007/s11033-014-3606-7 URL
[30]	Ribaut J M, Vicente M D, Delannay X. 2010. Molecular breeding in developing countries:challenges and perspectives. Current Opinion in Plant Biology, 13:213-218. doi: 10.1016/j.pbi.2009.12.011 pmid: 20106715
[31]	Rohlf F J. 1993. NTSYS-pc:numerical taxonomy and multivariate analysis system:version1.7. Exeter Software,Setauket.
[32]	Sahu P K, Mondal S, Sharma D, Vishwakarma G, Kumar V, Das B K. 2017. InDel marker based genetic differentiation and genetic diversity in traditional rice(Oryza sativa L.)landraces of Chhattisgarh,India. PLoS ONE, 12 (11):e0188864. doi: 10.1371/journal.pone.0188864 URL
[33]	Simona D S, Giovanni M, Rosamaria P, Antonio M, Vladan M, Stefania T. 2017. GATK hard filtering:tunable parameters to improve variant calling for next generation sequencing targeted gene panel data. BMC Bioinformatics, 18 (5):119-128. doi: 10.1186/s12859-017-1537-8 URL
[34]	Song X F, Wei H C, Cheng W, Yang S X, Zhao Y X, Li X, Luo D, Zhang H, Feng X Z. 2015. Development of InDel markers for genetic mapping based on whole genome resequencing in soybean. G3:Genes, Genomes,Genetics, 5 (12):2793-2799.
[35]	Steele K A, Ogden R, Mcewing R, Briggs H, Gorham J. 2008. InDel markers distinguish basmatis from other fragrant rice varieties. Field Crops Research, 105 (1):81-87. doi: 10.1016/j.fcr.2007.08.001 URL
[36]	Takahiro N, Kaoru D, Takashi M, Yukio N. 2020. Development of Indel markers for the selection of Satsuma mandarin(Citrus unshiu Marc.) hybrids that can be used for low-cost genotyping with agarose gels. Euphytica:International Journal of Plant Breeding, 216 (7):127-143.
[37]	Väli U, Brandström M, Johansson M, Ellegren H. 2008. Insertion-deletion polymorphisms(InDels)as genetic markers in natural populations. BMC Genetics, 9 (1):715-720.
[38]	Varshney R K, Nayak S N, May G D, Jackson S A. 2009. Next-generation sequencing technologies and their implications for crop genetics and breeding. Trends in Biotechnology, 27 (9):522-530. doi: 10.1016/j.tibtech.2009.05.006 pmid: 19679362
[39]	Wang Fu-sheng, Jiang Dong. 2010. Study on genetic background of specific citrus germplasm using CPSSR and EST-SSR markers. Acta Horticulturae Sinica, 37 (3):465-474. (in Chinese)
	王福生, 江东. 2010. 应用cpSSR和EST-SSR标记进行柑橘特异种质资源遗传背景研究. 园艺学报, 37 (3):465-474.
[40]	Wei Zhuang-min, Li Meng-meng, Yang Xiao-ming, Yuan Xiao-hui, Ye Jun-li, Xie Zong-zhou, Deng Xiu-xin, Chai Li-jun. 2020. Genetic identification of orange resource without nucleic acid‘Paotangi’. Acta Horticulturae Sinica, 47 (2):345-354. (in Chinese)
	韦壮敏, 李蒙蒙, 杨晓明, 袁晓慧, 叶俊丽, 谢宗周, 邓秀新, 柴利军. 2020. 无核酸橙资源‘抛橘’的遗传鉴定. 园艺学报, 47 (2):345-354.
[41]	Yan Jia-wen, Wu Xiao-xiao, Tang Yan, Chen Chuan-wu, Deng Chong-ling. 2021. Genetic diversity analysis of 11 citrus germplasm based on SRAP markers. Molecular Plant Breeding, 19 (2):664-671. (in Chinese)
	燕佳文, 武晓晓, 唐艳, 陈传武, 邓崇岭. 2021. 基于SRAP分子标记的11份柑橘种质材料遗传多样性分析. 分子植物育种, 19 (2):664-671.
[42]	Yuan Ping, Kong You-han, Wu Juan-juan, Yang Li-ying, Zhang Wen, Chen Peng, Li Xian-xin. 2017. Genetic relationship analysis of some pomelo varieties in Zhangjiajie based on SRAP molecular markers. Molecular Plant Breeding, 15 (12):5015-5022. (in Chinese)
	苑平, 孔佑涵, 吴娟娟, 杨莉颖, 张文, 陈鹏, 李先信. 2017. 张家界部分杂柚品种基于SRAP分子标记的亲缘关系分析. 分子植物育种, 15 (12):5015-5022.
[43]	Zhou Rui, Xie Kaidong, Wang Wei, Peng Jun, Xie Shanpeng, Hu Yibo, Wu Xiaomeng, Guo Wenwu. 2020. Rapid and efficient excavation of citrus tetraploid according to polyploid morphological characteristics. Acta Horticulturae Sinica, 47 (12):2451-2458. (in Chinese)
	周锐, 解凯东, 王伟, 彭珺, 谢善鹏, 胡益波, 伍小萌, 郭文武. 2020. 依据多倍体形态特征快速高效发掘柑橘四倍体. 园艺学报, 47 (12):2451-2458.

序号 No.	品种名 Name	采集地 Place	序号 No.	品种名 Name	采集地 Place
1	金堂绿柚 Jintang Lüyou	重庆Chongqing	25	桃溪蜜柚Taoxi Miyou	江西Jiangxi
2	北碚柚Beibeiyou	重庆Chongqing	26	金沙柚Jinshayou	江西Jiangxi
3	四季抛Sijipao	重庆Chongqing	27	金兰柚Jinlanyou	江西Jiangxi
4	梁沙柚Liangshayou	重庆Chongqing	28	凤凰柚Fenghuangyou	江西Jiangxi
5	暹罗柚Siamese Pummelo	重庆Chongqing	29	永嘉早香柚Yongjia Zaoxiangyou	江西Jiangxi
6	橘红彩柚Juhong Caiyou	重庆Chongqing	30	奥兰柚Oroblanco Grapefruit	广西Guangxi
7	彭县漳州柚Pengxian Zhangzhouyou	重庆Chongqing	31	橙柚Chengyou	广西Guangxi
8	纳西樱桃柚Naxi Yingtaoyou	重庆Chongqing	32	西施柚Xishiyou	广西Guangxi
9	安江石榴柚Anjiang Shiliuyou	重庆Chongqing	33	沙田柚Shatianyou	广西Guangxi
10	暹沙柚Xianshayou	重庆Chongqing	34	泰国晚金柚Thailand Wanjinyou	广西Guangxi
11	永安柚Yonganyou	湖南Hunan	35	云南脆香甜Yunnan Cuixiangtian	广西Guangxi
12	金香柚Jinxiangyou	湖南Hunan	36	泰国早2号Taiguozao 2	广西Guangxi
13	文旦柚Wendanyou	湖南Hunan	37	西双版纳1号Xishuangbanna 1	广西Guangxi
14	安江香柚Anjiang Xiangyou	湖南Hunan	38	鸡尾葡萄柚Cocktail Grapefruit	福建Fujian
15	冰糖柚Bingtangyou	湖南Hunan	39	星露比葡萄柚Star Ruby Grapefruit	福建Fujian
16	黔阳红心柚Qianyang Hongxinyou	湖南Hunan	40	麻步文旦柚Mabu Wendanyou	福建Fujian
17	左氏柚Zuoshiyou	湖南Hunan	41	泰国金丝柚Thailand Jinsiyou	福建Fujian
18	安江红心柚Anjiang Hongxinyou	湖南Hunan	42	尤溪橘柚Youxi Juyou	福建Fujian
19	土柚Tuyou	湖南Hunan	43	白肉琯溪蜜柚Bairou Guanximiyou	福建Fujian
20	缅甸柚Myanmar Pummelo	湖南Hunan	44	红肉琯溪蜜柚 Hongrou Guanximiyuo	福建Fujian
21	安江冰糖柚10号 Anjiang Bingtangyou 10	湖南Hunan	45	可口柚Kekouyou	广东Guangdong
22	华农红柚Huanong Hongyou	湖北Hubei	46	翡翠柚Feicuiyou	广东Guangdong
23	秭归蜜柚1号Zigui Miyou1	湖北Hubei	47	坪山柚Pingshanyou	广东Guangdong
24	秭归蜜柚2号Zigui Miyou2	湖北Hubei	48	火焰葡萄柚Flame Grapefruit	广东Guangdong

序号 No.	品种名 Name	采集地 Place	序号 No.	品种名 Name	采集地 Place
1	金堂绿柚 Jintang Lüyou	重庆Chongqing	25	桃溪蜜柚Taoxi Miyou	江西Jiangxi
2	北碚柚Beibeiyou	重庆Chongqing	26	金沙柚Jinshayou	江西Jiangxi
3	四季抛Sijipao	重庆Chongqing	27	金兰柚Jinlanyou	江西Jiangxi
4	梁沙柚Liangshayou	重庆Chongqing	28	凤凰柚Fenghuangyou	江西Jiangxi
5	暹罗柚Siamese Pummelo	重庆Chongqing	29	永嘉早香柚Yongjia Zaoxiangyou	江西Jiangxi
6	橘红彩柚Juhong Caiyou	重庆Chongqing	30	奥兰柚Oroblanco Grapefruit	广西Guangxi
7	彭县漳州柚Pengxian Zhangzhouyou	重庆Chongqing	31	橙柚Chengyou	广西Guangxi
8	纳西樱桃柚Naxi Yingtaoyou	重庆Chongqing	32	西施柚Xishiyou	广西Guangxi
9	安江石榴柚Anjiang Shiliuyou	重庆Chongqing	33	沙田柚Shatianyou	广西Guangxi
10	暹沙柚Xianshayou	重庆Chongqing	34	泰国晚金柚Thailand Wanjinyou	广西Guangxi
11	永安柚Yonganyou	湖南Hunan	35	云南脆香甜Yunnan Cuixiangtian	广西Guangxi
12	金香柚Jinxiangyou	湖南Hunan	36	泰国早2号Taiguozao 2	广西Guangxi
13	文旦柚Wendanyou	湖南Hunan	37	西双版纳1号Xishuangbanna 1	广西Guangxi
14	安江香柚Anjiang Xiangyou	湖南Hunan	38	鸡尾葡萄柚Cocktail Grapefruit	福建Fujian
15	冰糖柚Bingtangyou	湖南Hunan	39	星露比葡萄柚Star Ruby Grapefruit	福建Fujian
16	黔阳红心柚Qianyang Hongxinyou	湖南Hunan	40	麻步文旦柚Mabu Wendanyou	福建Fujian
17	左氏柚Zuoshiyou	湖南Hunan	41	泰国金丝柚Thailand Jinsiyou	福建Fujian
18	安江红心柚Anjiang Hongxinyou	湖南Hunan	42	尤溪橘柚Youxi Juyou	福建Fujian
19	土柚Tuyou	湖南Hunan	43	白肉琯溪蜜柚Bairou Guanximiyou	福建Fujian
20	缅甸柚Myanmar Pummelo	湖南Hunan	44	红肉琯溪蜜柚 Hongrou Guanximiyuo	福建Fujian
21	安江冰糖柚10号 Anjiang Bingtangyou 10	湖南Hunan	45	可口柚Kekouyou	广东Guangdong
22	华农红柚Huanong Hongyou	湖北Hubei	46	翡翠柚Feicuiyou	广东Guangdong
23	秭归蜜柚1号Zigui Miyou1	湖北Hubei	47	坪山柚Pingshanyou	广东Guangdong
24	秭归蜜柚2号Zigui Miyou2	湖北Hubei	48	火焰葡萄柚Flame Grapefruit	广东Guangdong

区域 Region	标记数量（比例） Number of markers（Percentage）	区域 Region	标记数量（比例） Number of markers（Percentage）
外显子 Exonic	7 311（1.67%）	内含子 Intronic	74 432（16.96%）
基因上游1 kb区域 Upstream	97 700（22.27%）	基因下游1 kb区域 Downstream	68 129（15.53%）
3'UTR	7 825（1.78%）	5'UTR	5 695（1.30%）
基因上游1 kb区域，同时也在另一基因下游1 kb区域 Up-and downstream	86 720（19.77%）	基因间区 Intergenic	90 938（20.73%）

区域 Region	标记数量（比例） Number of markers（Percentage）	区域 Region	标记数量（比例） Number of markers（Percentage）
外显子 Exonic	7 311（1.67%）	内含子 Intronic	74 432（16.96%）
基因上游1 kb区域 Upstream	97 700（22.27%）	基因下游1 kb区域 Downstream	68 129（15.53%）
3'UTR	7 825（1.78%）	5'UTR	5 695（1.30%）
基因上游1 kb区域，同时也在另一基因下游1 kb区域 Up-and downstream	86 720（19.77%）	基因间区 Intergenic	90 938（20.73%）

引物 Primer	正向引物（5′-3′） Forward primer	反向引物（5′-3′） Reverse primer
M4	TAGTGGCAACCGTGTGACTG	GAAGTTCCTTTTGTCTTTGTGGA
M6	TGCATGCATGTAGACAGATGTAG	CATCTTGTCGATGATCTGGTG
M8	AAATCTTGTTGTTAGTCTAATGTGTTG	AACTAAATCTTCTCTTTGACCATCC
M12	GGCCACTCGAGTTGGAATAA	AGGAGTGGCCATGTGGATAG
M19	GCCAAACGGGTCTTTAATTG	CATGAACTTTTGTTGGCGACT
M26	TGGAACCCAATTGATATGTGTC	TTATTCCCTTTTGCCGTCAG
M29	TTTTTCGTCTTCTGCAAGTATTGA	TAAGTGATAATGGGCACAGTTCTT
M32	GTGTTCATTGTCAGCGTTATACA	TTTTCGAGGGACAATGTCGT
M38	GTGGGATTATTGAGACCCACT	GGACTGCTGGGAATTTGGTA
M40	ACTGGTGCTCCCACATTAGG	ATTTGCAACCGTATGGGAAC
M47	CCACATGGCGATATAACATGA	CATCGCCCTTCTGATTCCT
M51	TGTTCTGACCATATTTGACCAAC	TGGGAGGGCATAAGAGAGTG
M62	TCCGTCGTCAATGACTTCAA	TGCTGCAGTTTTCTTTTTCAA
M63	AATCTGAGTTTTCCGAAACTTTTA	TTCGAATGTAGATGGAGGTCAA
M65	TGTCCGCAACTTTTAAGACG	TGAATAGGGTGGCTTGCTTT
M67	CACAGCGACATGCTTTCATT	GCTCCTAGTGACGTGATGCTT
M69	ATCCGAGCATTCAATTTTGTTT	CGGAGGGCAATTTGAATTTT
M72	CGGCATAAACTCTTGCAACTT	TCACAGGAGCAATTATGTCGTC
M73	TTACCGAGAGCCCTCAAATG	CCATCCTTATCAAGGACATGAA
M74	GGTCAAAAGTACCCCTTCTCG	TGGCCAAACGAACTTGTATTC
M84	AGCTGCAGGTCGCAATATCT	GGTAAGGCGGTGTGTGAAGT
M86	GGCCACCATGTTTAAGGAAA	GCCATATTATTGTTGAGATACAACTTT
M90	GCGTGAGCTTGTATCCTTGC	CTCGGTCCTCTGGATTTTCA
M93	CAGAGTTGCGAATTTATCAGAAAG	GCGTTACAACACAAAGCTTGA
